QU11220U Used Bare DRW Wheel Hub for 1994-1999 Ram 3500 Dually

QU11220U Used Bare DRW Wheel Hub for 1994-1999 Ram 3500 Dually. It is rare we have this Used Hub available! When we do, it's not available long.

See TKA11111 for New, USA made Hub!

Need More Info? Use the handy Links below to access over 40 years of Dan's product and vehicle specific Tech Notes to easily get the information you need for your vehicle's repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
4x4 Tech Help Bulletin
Matching Parts
Matching Spindle Socket/Parts
Safety Note
Applications

Tech Note 1: 4x4 Tech Help Bulletin
Need Wheel Bearing Adjustment Specs and Procedures? Order TSB4008 1994-2002 Dodge Rear Wheel Bearing Adjustment which shows you with photos and detailed text how to properly adjust the rear wheel bearings on your Dodge Ram 2500 or Ram 3500 4x2 or 4x4 Truck. Covers wheel bearing adjustment procedures for all 1994-2002 Dodge 3/4 Ton and 1 Ton Dodge Trucks equipped with Dana 60, Dana 70, or Dana 80 Full Float Rear Axles with either Single or Dual Rear Wheels.

Tech Note 2: Matching Parts
QU52315 Rear Wheel Bolt for 1994-2002 DRW Dodge RAM 3500
QU50376 Inner Wheel Bearing
QU50377 Inner Wheel Bearing Cup
QU50411 Outer Wheel Bearing Cup
QU50412 Outer Wheel Bearing
QU40451 Rear Wheel Seal
QU50075 Optional Double Lip Wheel Seal for 1994-2002
QU40078 Steel Axle Shaft Flange Gasket
QU90018 Pyroplex Synthetic Grease
TK8307 Master Rear Wheel Bearing and Seal Kit with Tools for 1994-2002 DRW Dodge Ram
TK8324 Rear Wheel Bearing and Seal Kit with Tools for 1994-2002 DRW Dodge Ram
QU40118 Locking spindle Nut for 1994-2002
QU40115 Lock Wedge must be used with QU40118 Locking Spindle Nut
TK11113 DRW Hub for 2000-2001 Drum Brakes
QU11162 DRW Hub for 2001-2002 Disc Brakes
QT1538 Rear Wheel Seal Installer for DRW Seal 1994-2002
QT1806 Inner Bearing Cup Installer
QT1801 Outer Bearing Cup Installer
QT1009i Spindle Nut Socket for 1979.5-2002
QT5500 Wheel Bearing Packer (Not large enough to handle DRW Inner Bearing).

Tech Note 3: Matching Spindle Socket/Parts
QU40115 Spindle Nut Lock Wedge or Key
QU40078 Axle Shaft Flange Gasket
QT1009i or QT1009 Spindle Nut Wrench
QU40367 Dana 60/70 Differential Cover Gasket
QU42029 Dana 60 Reusable Differential Cover Gasket
QU42030 Dana 70 Reusable Differential Cover Gasket
QU42031 Dana 80 Reusable Differential Cover Gasket.

Safety Note:
Stock Elastic Stop Spindle Nuts and Lock Wedges used on 1994-2002 Dodge Ram Dana 60, Dana 70, and 80 rear axles are designed to be installed once and only once! For safety reasons, you must discard both the nut and wedge if they are removed from the spindle for any reason. Both parts lose a percentage of their resistance of coming off when they are removed. You may hear of cases where this type of factory nut has come off while the truck was being driven. Invariably, these failures involve nuts and wedges that have been reused or improperly installed. NEVER REUSE FACTORY ELASTIC STOP SPINDLE NUTS and LOCK WEDGES!!!!!

Applications:
Dodge:
Ram 3500 Dually: 1994, 1995, 1996, 1997, 1998, 1999
