TK4865 Torque King® Dana 60, 61 Front Differential Master Service Kit

TK4865 Torque King® Premium Quality Dana 60, Dana 61 Front Differential Master Service Kit for your 1975-1993 Dodge Ram or 1977-1991 Chevy/GMC heavy-duty 4x4 truck's Dana 60 or Dana 61 front axle features 100% Timken® Bearings and genuine Dana-Spicer Small Parts. Torque King® Premium Diff Bearing and Seal Kits are the #1 choice for those who depend upon their truck to keep working day in and day out no matter how tough the conditions. Our Kits combine the superb quality of Timken bearings with the precise fit and reliability of 100% genuine Dana-Spicer small parts. No aftermarket, off brand or Chinese knockoff parts in these Kits! TK4865 includes: QU50400 Outer Pinion Bearing Cup, QU50401 Outer Pinion Bearing, QU50406 Inner Pinion Bearing Cup, QU50407 Inner Pinion Bearing, 2 QU50397 Differential Bearing Cups, 2 QU50398 Differential Bearings, Pinion Preload Shims, QU40365 Pinion Depth Shims, QU40207 Diff and Pinion Shim Kit (includes diff cover gasket and pinion nut), 12 QU40086 Ring Gear Bolts, QU40097 Pinion Seal, QU40099 Outer Pinion Slinger, QU40023 Pinion Washer, QU40519 Lock Pin, 2 QU40059 Axle Shaft Seals, QU90008 Gear Marking Compound, S82194 Ultra RTV Sealant, S24200 Threadlocker, and QT9404 Brush. Almost all parts USA Made, but some are imported.

Need More Info? Use the handy Links below to access over 40 years of Dan's product and vehicle specific Tech Notes to easily get the information you need for your vehicle's repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
Shims and Slingers
Service Procedures
Matching Parts
Applications

Tech Note 1: Shims and Slingers
This Kit fits Dana 60 and Dana 61 axles that axles used shims between the inner Pinion Bearing and the Pinion Head to set the pinion rotating preload. There may or may not have been a Slinger between the bearing and pinion head and/or a baffle under the cup. Pinion Shim Kits may fit several applications, so you may find you have a kit with an inner Slinger or baffle that differs from original. If present, these parts are part of the pinion height shim pack. As a rule, unless otherwise instructed, only use an inner baffle or Slinger if your axle was originally built with the exactly the same type of part. The only exception would be when the gear or shim manufacturer specifically instructs you to use a different combination than original equipment.

Tech Note 2: Service Procedures
Rebearing service procedures are covered in my TM4400 Pinion and Differential Bearing Service on Dana-Spicer Monobeam Axles.

Tech Note 3: Matching Parts
Exploded View XV1001 1975-1989 Dodge W250, W350 Dana 60/61 Front Axle
Exploded View XV1006 1977-1991 Chevy & GMC Dana 60 Front Axle

Applications

Chevy/GMC:
Chevy and GMC K30, K35, K3500, V3500: 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991

Dodge:
W200 with optional Dana 60, W300: 1975, 1976, 1977, 1978, 1979, 1980
W250 gas with optional Dana 60: 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993
W-250 Diesel: 1989, 1990, 1991, 1992, 1993
W350: 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993 (except mid 1980s W350LD with Dana 44 Front)
