Shop Now for 1992-1993 Dodge Ram New Venture NV4500 5 Speed Transmission Cases and Housings.
New Venture made a number of different 4500 main cases for General Motors and Chrysler. All are made of cast iron and have both left and right PTO covers. The two primary variations found in Dodge applications have identical top cover, input, and rear housing bolt patterns. The differences are with the reverse idler mounting. Listed below are the approximate Center to Center Bolt Pattern Dimensions and Input Retainer dimensions:
1994-1996 Dodge: Used with 5.61:1 Reverse.
Torque King p/n NV4500E, Casting# 18157 (Dodge)
Top: 10.078"
Bottom: 9.378"
Top to Bottom: 6.043"
Pilot for Input Shaft Retainer: 4.102".
Input Shaft Retainer Bolt Circle: 4.85"
1997-2005 Dodge: Used with 5.04:1 Reverse.
Torque King p/n NV4500L, Casting# 23167 or 33903
Top: 10.078"
Bottom: 9.378"
Top to Bottom: 6.043"
Pilot for Input Shaft Retainer: 4.1".
Input Shaft Retainer Bolt Circle: 4.85"
