XVJ110 1977-1978.5 Jeep CJ-7 Front Hub & Parts with Bendix Brakes
Interactive parts catalog for XVJ110 1977-1978.5 Jeep CJ-7 Front Hub & Parts with Bendix Brakes. Browse exploded diagrams, find part numbers, and order replacement parts.
XVJ110 1977-1978.5 CJ-7 Front Hub & Parts with Bendix Brakes
Information and Resources
XVJ110
Tools, Kits and Lubricants
XVJ110 Hub and Rotor
| Item | Part Number | Description | Qty |
|---|
| 1 | 50225 | QU50225 Inner Front Wheel Seal for IHC 1/2 Ton Truck, Scout, & Jeep CJ | 1 |
| 2 | 50630 | QU50630 Timken Taper Bearing used for Wheel, Diff, and Transmissions | 1 |
| 3 | 50629 | QU50629 Timken® Tapered Roller Bearing Cup | 1 |
| 4 | 80300 | QU80300 Front Wheel Stud for 1977-1985 Jeep CJ's with Disc Brakes | 1 |
| 5 | 80278 | QU80278 Premium 5 Bolt Front Disc Brake Rotor for Scout II & 77-78.5 CJ Front Axles | 1 |
| 6 | 15410 | QU15410 Front Bare Wheel Hub for 1962.5-1981 Jeep Dana 25, 27, 30 | 1 |
| 7 | 50447 | QU50447 Timken Differential/Wheel Bearing Cup | 1 |
| 8 | 50448 | QU50448 Timken Differential/Wheel Bearing | 1 |
| 9 | 15000 | QU15000 Spindle Flat Washer for Jeep & Scout with 1-5/8" Spindle Thread | 1 |
| 10 | 15001 | QU15001 Front 1-5/8" Thread x 2-1/16 Hex Spindle Nut for Jeep & Scout | 1 |
| 11 | 15002 | QU15002 Spindle Lock Washer for Jeep and Scout | 1 |
| 12 | 4669 | QK4669 Hex Spindle Nut Kit for Jeeps and IHC Scouts | 1 |
| 13 | 15005 | QU15005 6 Bolt Front Hub Gasket | 1 |
XVJ110 Tools
| Item | Part Number | Description | Qty |
|---|
| 1 | 1075 | QT1075 1/2" Drive Ball Joint Adjuster Sleeve Socket for Dana 30, Dana 44, GM 10 Bolt, Roxor | 1 |
| 2 | 881011 | QT1011 2-1/16" Hex Front Spindle Nut Socket Jeep IHC | 1 |
| 3 | 5500 | QT5500 Wheel Bearing Packer With Cover | 1 |
| 4 | 1802 | QT1802 Bearing Cup Installer 2-7/8" Approximate Outside Diameter | 1 |
| 5 | 1508 | QT1508 Front Wheel Seal Installer for IHC Scout, Jeep CJ & Scrambler | 1 |
| 6 | 1100 | QT1100 1" X 8" Driver Handle for Installers & Removers with 5/8" Tip | 1 |
XVJ110 Kits
| Item | Part Number | Description | Qty |
|---|
| 1 | 56112 | QU56112 Mile Marker 35 Spline Stainless Steel Hub Set | 1 |
| 2 | 134907 | TK4907 Front Wheel Bearing Kit for CJ, Scrambler, Scout II Disc Brakes | 1 |
| 3 | 4669 | QK4669 Hex Spindle Nut Kit for Jeeps and IHC Scouts | 1 |
