TK4947 94-99 Master Free-Spin Kit with Warn® Lock-Out Hubs & Install Tools

TK4947 Torque King® Master Free-Spin Kit Warn® Premium Bronze Dial Lock Out Hubs with Axle U-Joints and Install Tools for 1994-1999 Dodge Ram 2500, Ram 3500 trucks with single rear wheels. Includes all the parts, special assembly tools, and extras needed to upgrade your heavy-duty Ram 4x4's front axle to low-cost serviceable wheel bearings and your choice of fuel-saving lockout hubs. The heart of all these comprehensive Kits are USA made Dynatrac Front Free-Spin™ Hub Kit which includes heat-treated chromoly spindles with spindle bearing, spindle seals, Timken® wheel bearings, Timken® or Dana wheel seals, 35-spline 1.50-inch chromoly outer shafts, 8 bolt wheel hubs, your choice of Hub Locks, double spindle nut kit, and instructions. PLUS, our comprehensive Master Kits ALSO include Spindle Nut Socket, Torque King® greaseable Axle U-Joints, wheel seal tools, bearing packer, synthetic wheel bearing grease, threadlocker, and anti-seize compound. NOTE: The 1994-1999 Dynatrac Wheel Hubs and Axle Shafts are NOT compatible with trucks having 4 Wheel ABS (Anti-Lock Brake System). Will also fit dually models with optional wheel adapters, see Tech Note 4 if you have a Dodge Ram 3500 with Dual Rear Wheels (DRW).

Available Master Kits:
TK4947 Master Kit with Warn® Premium Bronze Dial Lock Out Hubs
TK4948 Master Kit with Dynatrac DynaLoc™ Heavy-Duty Lock Out Hubs (extra cost option)
TK4955 Master Kit with Mile Marker® Stainless Steel Lock Out Hubs (price reduction option)

For available Parts-Only Dynatrac Free-Spin™ and Yukon Spin Free® Kits, see Product Note 1 below.

Need More Info? Use the handy Links below to access over 40 years of Dan's product and vehicle specific Tech Notes to easily get the information you need for your vehicle's repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
1994-1999 Conversion Kit Chart
Included Components
Kit Differences
Ram 3500 Dually
Anti-Lock Brakes
Will NOT fit Dana 44 Axles
Disassembly/Assembly
Ball Joints
Includes
Inspect
Front Axle Disassembly
CAD System
Matching Parts
Applications

Tech Note 1: 1994-1999 Conversion Kit Chart

Tech Note 2: Included Components

Tech Note 3: Kit Differences
The only component difference between TK4947, TK4948, and TK4955 Kits is the lock out hubs. TK4947 is the most popular, which includes TK56120 Warn Premium Hubs. TK4948 includes TK11258 heavy-duty Dynaloc™ Hubs. TK4955 comes with QU56112 Mile Marker Stainless Steel Hubs.
All three Kits include the following Components:
TK11247 Dynatrac Free-Spin™ Kit
(2) TK40715 Torque King® Factory Lubed Universal Joints intalled in outer shafts
QT1025 Spindle Nut Socket for adjusting the wheel bearings
QK4964 Install Kit

Tech Note 4: Ram 3500 Dually
If you have a Dodge Ram 3500 dually, your factory dual wheel hub adapters will have to be changed as they have insufficient clearance for the new lockout hubs included in our Kits. Order optional QU42072 Dual Wheel Adapter Set.

Tech Note 5: Anti-Lock Brakes
TK4947 Kits are only compatible with trucks equipped with Rear Wheel Anti-Lock Brake Systems. There are no provisions for an axle shaft ABS tone ring (used on 1994-1997 models with 4 wheel ABS) or hub mounted tone ring (used on 1998-1999 trucks with 4 wheel ABS).

Tech Note 6: Will NOT fit Dana 44 Axles
TK4947 Kits fit 1994-1999 Dodge Ram 2500, Ram 3500 with Rear Wheel ABS, Dana 60 front axles and a Gross Vehicle Weight rating of 8800 pounds or higher. These Kits will NOT fit 1994-1997 Ram 2500 trucks with Dana 44 axles which have a GVW rating under 8800 pounds.

Tech Note 7: Disassembly/Assembly
To install TK4947 Kit, you need to remove the original hubs and axle shafts. Depending upon age, mileage, and use, your truck may also need inner axle shaft oil seals, ball joints, brake parts, or pinion seal. Inspect the axle before disassembly for worn or damaged parts and order those extra parts/tools you desire for a first class job.  Given the era of trucks this Kit fits, I STRONGLY recommend you replace the inner axle seals which can become hard and brittle with age. For Inner Axle Shaft Seal Kits with oil seals and installation tools see QK4620.

Tech Note 8: Ball Joints
We also stock TK42057 Dynatrac, Heavy-Duty greaseable and rebuildable Ball Joints for your 1994-1999 Dodge Ram.

Tech Note 9: Includes
Torque King Premium TK4947 Kits INCLUDE QK4964 Tool and Lube Kit which has the extras you need for a pro-quality installation. All the components are also available separately. QK4964 includes:
QT1505 Wheel Seal Installer
QT1100 Drive Handle for Seal Installer
(2) QU90018 14 oz. Tubes Pyroplex Plus Synthetic Grease (One is used to fill the Bearing Packer)
S9975 Anti-Seize (Use between the spindle and knuckle and on the brake shield mating surfaces)
QT9404 Brush for applying anti-seize
QT5500 Bearing Packer with Cover

Tech Note 10: Inspect
TK4947 Kits include two TK40724 Torque King® Premium Greaseable axle universal joints pre-installed in your new outer axle shafts. To install this Kit, you need to remove the original hubs and axle shafts. Depending upon age, mileage, and use, your truck may also need inner axle shaft oil seals, ball joints, brake parts, or pinion seal. Inspect the axle before disassembly for worn or damaged parts and order those extra parts/tools you desire for a first class job.

Tech Note 11: Front Axle Disassembly
The first time a 1994-1999 era Ram 2500, Ram 3500 Dana 60 front axle has to come apart, it is usually an absolute WITCH to separate the factory wheel hub assemblies from the steering knuckle as Dana did not use any anti-corrosion compound between the wheel hub flange and steering knuckle. The good news is since you are replacing the original hubs, you do not have to worry about them separating or getting damaged during the removal process.

Tech Note 12: CAD System
Installing a Dynatrac Free-Spin™ Kit is a great improvement over the factory live spindle design, but the troublesome vacuum controlled Central Axle Disconnect (CAD) system is still there. You have three choices for the CAD system.

Tech Note 13: Matching Parts
Matching Parts for TK4947 Front Hub Upgrade Kits:
QU40220 Dana Original Equipment Replacement Ball Joint Kit for 1 Side
QK4758 Greaseable Ball Joint Kit
TK42057 DynaTrac Rebuildable and Greaseable Ball Joint™ Kit
QU11309 CAD Delete Kit with 1 Piece Inner Axle Shaft
QU40090 CAD Housing Gasket for Central Axle Disconnect
QU40247 15 Spline Right Inner Axle Shaft
QU40350 Left Inner Axle Shaft
QU40300 Right Differential Output Shaft 30 splines inboard x 15 splines outboard
QU40387 30 Spline Differential Gear Kit
QU10959 Brake Shield for Axles without 4 Wheel ABS
QU10961 Brake Shield Spacer for Axles without 4 Wheel ABS
QU10614 Hub to Knuckle Bolt
QU40367 Dana Original Equipment Model 60/70 Differential Cover Pan Gasket
QU42029 Dana Reusable Model 60 Differential Cover Pan Gasket
QK4620 Inner Axle Shaft Seal Kits with Installation Tools

Applications
Dodge Ram:
Ram 2500 with Dana 60 Front Axle and Rear Wheel ABS: 1994, 1995, 1996, 1997
Ram 2500 with Rear Wheel ABS: 1998, 1999
Ram 3500 Single Rear Wheel Trucks with Rear Wheel ABS: 1994, 1995, 1996, 1997, 1998, 1999
Ram 3500 Dual Rear Wheel Trucks with Rear Wheel ABS (Also Requires Optional Wheel Adapters): 1994, 1995, 1996, 1997, 1998, 1999
