Description
QK3064 1994-2002 40mm Premium Metric Midship Support Rear Driveshaft Center Bearing Kit for 1994-2002 Dodge Cummins Diesel or Heavy-Duty Gas Ram 2500 and Ram 3500 series 3/4 ton and 1 ton trucks includes genuine original equipment Center Bearing, Large Front Slinger, Small Rear/Slinger/Retainer, 2 QU10912 Special Bolts with attached flat washer, 1 each QU40084, QU40133 Driveshaft Boot Clamps, and S9978 Medium Strength Threadlocker. Fits both 4x4 and 4x2 trucks. Center Bearing Assembly USA Made using domestic and imported parts. Clamps Made in Canada, Threadlocker USA Made.
Also See: QU40718 Replacement Center Bearing with 7/16" Mounting Holes
Need More Info? Use the handy Links below to access over 40 years of Dan's product and vehicle specific Tech Notes to easily get the information you need for your vehicle's repair, maintenance, or upgrade project!
Dan the Gear Man® Tech Notes:
Installation
Mounting Hole Threads
Exploded Views
Applications
Video
Tech Note 1: Installation
Driveshaft Center Bearings need to pressed on and off your rear driveshaft. See TM3000 Driveshaft Manual or TSB3506 for service procedures.
Tech Note 2: Mounting Hole Threads
Dodge used both 10mm Metric and 7/16" Standard bolts to attach the Center Bearing to the Carrier Bearing Mounting Bracket. Except for the threaded mounting holes, the two Bearing Assemblies and included slingers are exactly the same. There is no firm break point for what trucks have either the metric or standard bearing, so to simplify your purchase process, our QK3064 Kit includes an original equipment Bearing Assembly AND the OEM QU10912 metric metric Class 10.9 hardened mounting bolts. If you would prefer a bearing with the 7/16" holes, order our our QU40718 bearing and if needed, 2 QU11102 (Grade 5) or (2) QU10806 (Grade 8) 7/16" mounting bolts.
Tech Note 3: Exploded Views
Available Exploded Views that Show this Part:
XVD520 1994-1997 Dodge Ram 2500, Ram 3500 2 Piece Rear Driveshaft
Applications:
Dodge:
Ram 2500, Ram 3500 with 2 piece rear driveshaft: 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002
Warranty
Product Reviews
-
Center Support Bering
Great part ..... Nicely packaged.... Worked as it should..... Looks to be made in the US
