TK11834 Rear Inner Wheel Bearing Cup for 2019-up Ram 3500 Pickup DRW Trucks with 2-1/2" Spindle Nuts fits 2019-up Ram 3500 Dual Rear Wheel Pickup Trucks with the Cummins Diesel High Output (Engine code ETM) and AAM 12.0 12" rear axles. Sold individually.
Need More Info? Use the handy Links below to access over 40 years of Dan's product and vehicle specific Tech Notes to easily get the information you need for your vehicle's repair, maintenance, or upgrade project!
Dan the Gear Man® Tech Notes:
Always Replace
Grease
Matching Parts
Applications
Tech Note 1: Always Replace
Always replace the cup and cone at the same time.
Tech Note 2: Grease
To obtain maximum life from a wheel bearing, it must be properly lubricated. The long term wheel bearing lubrication is provided by oil from the differential that flows down the axle tubes and get trapped in the wheel hubs, however, the bearings must be lubricated to provide initial lubrication until oil from the diff works it's way down. Coat the inside hub and bearing cup surfaces with 75w85 synthetic axle lubricant. Pack the bearings with a clean NLGI #2 disc brake approved wheel bearing grease.
Tech Note 3: Matching Parts
XVD283 2019-up Ram 3500 DRW Hub Exploded View
TK11832 Wheel Seal
TK11837 Inner Wheel Bearing
TK11833 Outer Wheel Bearing
TK11836 Outer Wheel Bearing Cup
TK11839 Axle Shaft O-Ring
TK11716 Spindle Nut
QU30123 Spindle Nut Lock Key
TK11838 Spindle Nut Lock Ring
TK11840 Axle Shaft Bolt
S24200 Medium strength Blue Threadlocker for the axle shaft flange bolts
TK11835 DRW Hub, 2019-2020
TK11842 DRW Hub, 2021-2022
Applications
RAM:
Ram 3500 DRW Pickup Trucks with AAM 12" Rear Axles and High Output Cummins (Engine Code ETM): 2019, 2020, 2021, 2022
