QU11167 New 52105028AD 23 Spline NP241DHD Transfer Case Assembly

Obsolete. No Longer Available.

QU11167 Brand New 52105028AD 23 Spline New Venture NP241DHD Manual Shift Transfer Case Assembly for 2002 Dodge Ram 2500, Ram 3500. This is a BRAND NEW, complete New Venture NP241DHD manual shift transfer case for Ram 2500 and Ram 3500 trucks with 23 spline output automatic transmissions. Slip yoke style rear output. Pickup at store or Truck Shipment only.

Need More Info? Use the handy Links below to access over 40 years of Dan's product and vehicle specific Tech Notes to easily get the information you need for your vehicle's repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
Check Oil
Other Applications
Slip Yoke
Gasket
Applications

Tech Note 1: Check Oil
These transfer cases are shipped by New Venture with a factory fill of oil, but leakage can occur during shipping if the case is tipped. Always check the oil level after installation and refill as needed.

Tech Note 2: Other Applications
QU11167 assembly is the last production model of 52125028 NP241DHD series of transfer cases. The transfer case itself will physically fit in place of earlier 1998-2002.5 52105028, 52105028AB, 52105028AC transfer cases but there are two differences that you need to be aware of if you wish to use this case to replace one of the earlier models. QU11167 transfer case was used on 2002 model year trucks without the vacuum controlled central axle disconnect so it is not synchronized and it has a different shift cam with an electric indicator switch instead of of a vacuum switch. To replace a 52105028, 52105028AB, or 52105028AC transfer case, you will have to make a simple spacer to permanently move the front axle shift fork into the engaged position.

Tech Note 3: Slip Yoke
The rear output shaft has 31 splines. If you need a matching slip yoke, order QU40354 OEM replacement slip yoke.

Tech Note 4: Gasket
Dodge did not use a gasket between the transmission and transfer case as both the transmission output shaft and transfer case input shaft are sealed. However, you can use TK10519 Transmission to Transfer Case Gasket if you wish.

Applications
Dodge NP241DHD:
Direct Replacement for 2002 Ram 2500, Ram 3500 with auto trans but without vacuum controlled Central Axle Disconnect
Will also dimensionally fit 1998-2002.5 Ram 2500, Ram 3500 with automatic transmission and CAD (See Tech Note 2)
