QK4512 Dana 60 Front King Pin Kit

QK4512 Dana 60 Front King Pin Kit for 1975-1993 Chevy, Dodge, Ford, GMC, and IHC trucks with Model 60 and 61 King Pin type front axles. Complete Kit for both sides includes 2 each of these genuine Dana Spicer original equipment parts: QU40191 King Bearing/Seal Sets, QU40063 Upper King Pin Gasket, QU40157 Spring Plate, QU40265 Tension Spring, QU40093 Upper King Pin Bushing. Kit also includes Anti-Seize, Threadlocker, Disc Brake Lube, RTV Sealant, & Cotter Keys for the tie rod ends.

Order optional QT1018 Large 4 Prong Socket, or QT1025 Universal Front & Rear Spindle Nut Socket separately, depending on your truck year & model, for your spindle nuts & serviceable wheel bearings.

Need More Info? Use the handy Links below to access over 40 years of Dan's product and vehicle specific Tech Notes to easily get the information you need for your vehicle's repair, maintenance, or upgrade project!

Dan the Gear Man® Tech Notes:
Kit Components
Durable
Service Guide
Spindle Nut & Wheel Hub Configurations
Matching Parts
Applications

Tech Note 1: Kit Components
QK4512 Kit Includes:
(2) QU40191 Lower King Pin Kit
(2) QU40063 Upper King Pin Gasket
(2) QU40157 King Pin Spring Plate
(2) QU40265 Upper King Pin Spring
(2) QU40093 Upper King Pin Bushing
S24200 6ml Blue Threadlocker
S81343 1oz. Anti-Seize Compound
QT9404 Application Brush
S20356 Synthetic Brake Lube
QU90006 3.35oz. Ultra Black RTV Sealant
(2) QU95078 1/8"x1.25" Cotter Key

Tech Note 2: Durable
Of all the King Pin and Ball Joint configurations used on 3/4 and 1 ton 4x4 trucks, none is as durable as the Dana Spicer King Pin Open Knuckle design that was introduced in the 1975 model year. Unfortunately, for one reason or another, all the vehicle manufacturers switched to ball joints in the early 1990's with GM and Ford dropping the design after 1991, while Dodge used it until 1993.

Tech Note 3: Service Guide
Need help servicing your King Pins? See my VSG4506 King Pin Video Service Guide!

Tech Note 4: Spindle Nut & Wheel Hub Configurations
Several spindle bearing nut and wheel hub configurations were used on King Pin equipped axles. Additional stocking service parts you will need for:
Chevy/GMC: 1977-1981 order QU40037 Spindle Lock Washer, QU40065 Large Spindle V-Seal, QU40148 Small Spindle V-Seal, QU40066 Spindle Thrust Washer separately
Dodge: 1976-1990 order QU40051 Spindle Lock Washer and QU50216 Hub Flange Gasket separately
Ford: 1978-1979, 1985 order QU40037 Spindle Lock Washer separately

Tech Note 5: Matching Parts
Exploded View XV1006 1977-1991 Chevy/GMC 1 Ton Dana 60 Front Axle
Exploded View XV1001 1975-1989 Dodge W250, W350 Dana 60/61 Front Axle
Exploded View XV1004 1990-1993 Dodge W250, W350 Dana 60/61 Front Axle
Exploded View XV1015 1985-1991 Ford F350 Dana 60 Front Axle

Applications

Chevrolet Dana 60:
K30, K3500: 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987
K3500/V3500 1 Ton (square cab models): 1988, 1989, 1990, 1991

Dodge Dana 60, 61:
W-350 1 Ton*: 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993
W-250 all with Cummins Diesel: 1989, 1990, 1991, 1992, 1993
*For some reason, a few mid 1980's W-350 single rear wheel trucks have a wimpy Model 44 axle!

Ford Dana 60:
Heavy-Duty F-250, F-350: 1978, 1979
F-350: 1985-1/2, 1986, 1987, 1988, 1989, 1990, 1991

GMC Dana 60:
K35, K3500: 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991
K3500/V3500 1 Ton (square cab models): 1988, 1989, 1990, 1991

International:
1300 Camper Special: 1975
